Powered by the Intel® Core™ i5-13420H processor (45W, 8C/12T). To address the platform's native MAC count limitations, two independent network controllers are bridged via the chipset's underlying PCIe lanes.
The rear I/O panel natively integrates 3 x RJ45 Gigabit LAN ports featuring independent bandwidth, alongside 6 x USB 3.2 interfaces. This architecture ensures congestion-free packet transmission and zero frame drop for multiple GigE / USB3 Vision industrial cameras operating under hardware synchronous triggering.
Product Core Advantages
Engineered for AOI and factory automation, Hibertek’s Machine Vision System achieves the perfect balance between high-performance computing and massive bandwidth within an ultra-compact footprint.
High-Performance H-Series (45W TDP)
Powered by the Intel® Core™ i5-13420H processor (8C/12T), the system delivers a robust 45W of raw processing power. This ensures ultra-low latency and smooth execution of complex defect-detection algorithms while processing multiple high-resolution industrial camera streams.
Independent Bandwidth & High-Density I/O
Utilizing precise PCIe lane bridging, the rear I/O features 3x independent Gigabit LAN ports and 6x USB 3.2 interfaces. This architecture guarantees congestion-free data transmission and Zero Frame Drop when multiple GigE or USB3 Vision cameras operate simultaneously under heavy loads.
Advanced Active Cooling System
To manage the thermal demands of a 45W high-performance CPU, the system combines an extruded aluminum chassis with an industrial-grade PWM smart fan and pure copper heat spreaders. This forced-convection design rapidly exhausts heat, ensuring the device sustains peak performance without thermal throttling in rigorous factory environments.
Cable-less & Rugged Hardware Architecture
By integrating all vision interfaces directly onto the motherboard, we have eliminated the need for internal ribbon cables or external PCIe expansion cards. This cable-less design maximizes signal integrity, reduces the Z-axis profile, and completely prevents hardware failure caused by mechanical vibrations in industrial machinery.
Real-World Deployment:
Factory Automation
In the demanding environment of smart factories, our Machine Vision System acts as the high-speed "eyes and brain" for automated production lines. Built to handle the rigors of 24/7 manufacturing, the system excels in high-speed sorting, precision assembly, and real-time quality inspection
Key Benefits for Big Screen Use:
-
Zero Frame Drop: Dedicated bandwidth for high-speed inspection cameras.
-
Thermal Resilience: Active cooling prevents performance dips in hot factory floor conditions.
-
Space-Saving: Slim Z-axis profile allows for easy integration into existing machine enclosures.
Hardware Architecture Summary
Exclusive Custom Designs
This is one of our exclusive custom designs. To protect client confidentiality, full specifications and certain images are restricted. Contact us to discuss similar solutions for your project.
